Data to RDF Mapping Language (D2RML) Specification

Document Conventions

In this document, examples assume the following namespace prefix bindings unless otherwise stated:

Logical Blocks and Logical Extensions

The core mechanism for generating RDF triples in D2RML are maps, which are rules for generating RDF terms (subjects, predicate, objects, named graphs), entire RDF triples, as well as plain text lines from the elements of the data obtained from the information sources over which the iteration takes places.

D2RML assumes that such iterations take place over logical blocks. A logical block is a piece of data can be considered to consist of a series of objects of identical structure that can be iterated over. These objects are the logical rows of the logical block. They logical rows can be e.g. rows of relational tables, XML elements of XML documents, JSON objects of JSON documents, etc.

The logical rows of a logical block are considered to be logically divided into logical columns, which represent subparts of each logical rows, and they are identified and are accessible through a column name. The notion of a logical column is abstract, and a logical column may in fact be virtual. E.g. the logical columns of a relational row are the columns defined by the underlying table schema, while the logical columns of an XML element, are any sequence of objects returned by an XPath expression; these sequences are identified by the respective XPath query.

Each logical column within a logical row represents a logical cell. The logical cell content is an ordered set of zero or more value elements, which are computed by evaluating the respective column name expression against the contents of the current logical row (e.g. in the previous example of an XPath query against the XML element corresponding to the current logical row).

The value elements of logical cell contents have a value type, which can be either IRI or literal. A literal may be a typed literal and hence have a datatype (a XML Schema built-in datatype defined in [[XMLSCHEMA11-2]], rdf:HTML or rdf:XMLLiteral). The value type of a logical cell content's value element reflects their type in the original data form underlying the logical block.

In the case of logical tables, logical cell contents consist of at most one value element, since the underlying data structure is tabular and evaluating a column name returns that value element. However, in the case of logical arrays, logical cell contents may consist of more than one value elements. Since in this case in general the column name may be e.g. an JSONPath or XPath expression, and its evaluation in general returns an array of objects, these objects are the value elements in the corresponding logical cell content, in the order returned by the evaluating expression.

A key concept in D2RML is that a logical row can be expanded by logical extensions. A logical extension extends a logical row by appending to it a new logical block (obtained e.g. from another information source.) The new logical block does not need to be of the same type as that of the original logical row, (e.g. the original logical block may consists of relational table rows, and the extended block of XML elements), and a logical row may be extended by more than one logical extensions of possibly different types. Each logical extension should be characterized by a unique name, so that it can be referenced. The column names within the logical extension are accessible though by a combination of the extension name and the column name within the logical extension.

Value Maps

The logical cell contents of logical blocks and logical extensions are used to generate the output data of a D2RML document. The actual values to be used for generating output content are obtained from the value elements of logical cell contents, through value maps. A value map is a rule for transforming the value elements of logical cell contents into a value set, where a value set is an ordered set or zero or more derived value elements. The derived value elements can be of value type IRI, literal or blank node.

A value map works with the strings of IRIs and the lexical forms of literals, which it cannot change. It can simply change their value type, change the datatype of literals, or produce new IRIs or literals by combining strings of IRI, lexical forms of literals, and fixed strings. Manipulation of the actual strings of IRIs and of the lexical forms of literals can be achieved through defined columns that provide a way to apply data manipulating functions on them.

Evaluation of Maps

Value sets by maps generate RDF terms (e.g. subjects, predicates, objects) and other elements. When a value set contains more than one value elements, then the map values for each one of the elements of the underlying values set. When a map operated on more than one values sets that have to be combined and both contain more than one value elements, then the map produced elements corresponding to all combinations of values elements from the involved values sets. E.g. if a subject map produces k subjects, a predicate map produces m predicates, and an object map produces n objects, and these maps are parts of the same triples map, k*m*n triples will be produces.

This evaluation strategy is applied in all cases involving maps, e.g. when a function is evaluated and for its arguments maps producing more than one value elements are provided.

Current D2RML Document Source

The current D2RML document source is a concrete file source which represents the D2RML document currently being processed by the D2RML processor as an RDF dataset. Its is represented by the individual dr:CurrentD2RMLDocumentSource.

<#RDFDataset>
   dr:logicalGraph [
      dr:source dris:CurrentD2RMLDocument ;
      dr:namedGraph <#DataTriples> ;
   ] .

<#DataTriples> {
   ex:101 rdfs:label "Company 101" .
   ex:102 rdfs:label "Company 102" .
}


Transient RDF Datasets

A transient RDF dataset in an information source which represents an initially empty RDF dataset that should be created by the D2RML processor upon processing the underlying D2RML document. A transient RDF dataset is an instance of dr:TransientRDFDataset. A D2RML document may contain several transient RDF datasets.

Typically, a transient RDF dataset will serve as the logical output for one or more triples maps, rdf maps or triples datasets, i.e. elements that cause the D2RML processor to produce RDF triples, and used as an information source by other triples or plain text generating elements. A transient RDF dataset cannot be parametric.

<#TempDataset>
   a dr:TransientRDFDataset ;


Logical Graphs

A logical graph represents an interpretation of a data block provided from an information source as an RDF graph [[RDF11-CONCEPTS]]. It is an instance of dr:LogicalGraph. The following example shows how a TRIG file can be interpreted as a logical graph.

<#TRIGFile>
   a dris:FileSource ;
   dris:path "c:/data/dataset.trig" .

<#LogicalGraph>
   a dr:LogicalGraph ;
   dr:source <#TRIGFile> .


In the above example the RDF graph represented by the logical graph is the default graph of the underlying TRIG file. If another named graph is desired, it can be specified by the dr:namedGraph property.

<#TRIGFile>
   a dris:FileSource ;
   dris:path "c:/data/dataset.trig" .

<#LogicalGraph>
   a dr:LogicalGraph ;
   dr:source <#TRIGFile> ;
   dr:namedGraph <http://example.org/companies/> .


<#LogicalGraph>
   dr:logicalGraph [
      dr:source dr:CurrentD2RMLDocumentSource ;
      dr:namedGraph <#Data> ;
   ] .

<#Data> {
   <http://example.com/companies/C145>
      a   dcterms:Agent ;
      dcterms:title "International Company"@en  ;
      foaf:homepage <https://www.international-company.net/> .
}


Logical Blocks

Logical blocks are a key concept in D2RML and have been introduced in Data Model Section; they are logical inputs that consist of a series of objects of identical structure that can be iterated over (the logical rows). The abstract class of logical block is dr:LogicalBlock.

An iterator iterating on the logical rows of a logical block typically consumes all rows starting from the first row (with index 0) and continuing until the last row. This can be changed by specifying an offset and a limit using the dr:offset and dr:limit properties respectively. The offset is the index of the logical row from which the iterator should start consuming rows, and limit is the number of subsequent logical rows that will be consumed by the iterator. If no offset is specified, it is assumed to be 0, whereas if no limit is specified the iterator will consume all logical rows starting from to offset index until the last logical row.

D2ML defines three types of logical block: logical tables, logical arrays and set tables.

<#CompaniesSource>
   a dris:FileSource ;
   dris:path "d:/data/companies.csv" .

<#CompaniesMapping>
   dr:logicalBlock [
      a dr:CSVTable ;
      dr:source <#CompaniesSource> ;
      dr:delimiter "\t" ;
      dr:headerRecord true ;
      dr:quoteCharacter "\""
   ] ;
   ...


<#CompaniesSource>
   a dris:FileSource ;
   dris:path "d:/data/companies.xlsx" .

<#CompaniesMapping>
   dr:logicalBlock [
      a dr:Spreadsheet ;
      dr:source <#CompaniesSource> ;
      dr:sheetName "Sheet1" ;
      dr:offset 1
   ] ;
   ...


<#WikidataEndpoint>
   a is:SPARQLEndpoint ;
   is:uri "https://query.wikidata.org/bigdata/namespace/wdq/sparql" .

<#Mapping>
   dr:logicalBlock [
      a dr:SPARQLQueryResult ;
      dr:source <#WikidataEndpoint> ;
      dr:sparqlSelectQuery "PREFIX wd:  PREFIX wdt:  SELECT ?entity WHERE { ?entity wdt:P31 wd:Q11424 }"
   ] ;
   ...


<#RDFDataSource>
   a dris:HTTPSource ;
   dris:uri "http://www.example.org/data/companies.ttl" .

<#Mapping>
   dr:logicalBlock [
      a dr:SPARQLQueryResult ;
      dr:source <#RDFDataSource> ;
      dr:sparqlSelectQuery "PREFIX ex:  SELECT ?id WHERE { ?id a ex:Company }" ;
   ] ;
   ...


<#DataSource>
   a dris:HTTPSource ;
   dris:uri "http://www.example.org/data/data.json" .

<#Mapping>
   dr:logicalBloack [
      a dr:JSONItemArray ;
      dr:source <#DataSource> ;
      dr:iterator "$.companies" ;
      dr:iteratorLanguage drel:JSONPath ;
      dr:columnLanguage drel:JSONPath
   ] ;
   ...


<#DataSource>
   a dris:HTTPSource ;
   dris:uri "http://www.example.org/data/data.xml" .

<#Mapping>
   dr:logicalBlock [
      a dr:XMLItemArray ;
      dr:source <#DataSource> ;
      dr:iterator "//companies" ;
      dr:iteratorLanguage drel:XPath ;
      dr:columnLanguage drel:XPath
   ] ;
   ...


<#DataSource>
   a dris:HTTPSource ;
   dris:uri "http://www.example.org/data/data.html" .

<#Mapping>
   dr:logicalBlock [
      a dr:RegExItemArray ;
      dr:source <#DataSource> ;
      dr:iterator "<table id='companies'>(.*?)<table>" ;
      dr:iteratorLanguage drel:RegExJava ;
      dr:columnLanguage drel:RegExJava
   ] ;
   ...


   <record>
      <inscription.type>signature</inscription.type>
      <inscription.position>left</inscription.position>
      <inscription.type>date</inscription.type>
      <inscription.position>right</inscription.position>
      ...
   </record>


   dr:predicateObjectMap [
      dr:predicate ex:inscription ;
      dr:objectMap  [
         dr:parentTriplesMap [
            dr:logicalBlock [
               a dr:SetTable ;
               dr:transferedColumns ( [ dr:column "//inscription.type" ]
                                      [ dr:column "//inscription.position" ] ) ;
            ] ;
        ...
        ]
      ]
   ]


Mapping Datasets

A mapping dataset represents the contents of a logical block together with some instructions for generating new data from the contents of the logical block. The logical block is specified using the dr:logicalBlock property.

The content generation instructions of a mapping dataset can be a triples map, an RDF map or a text lines map. The first two, which are specified by a dr:triplesMap and dr:rdfMap property, respectively, generate RDF datasets, while the latter, which is specified by a dr:textLinesMap property generates lines of plain text. A mapping dataset MAY have zero or more triples maps, RDF maps and text lines maps, but MUST have at least one of them.

A triples map, an RDF map or a text lines map contained within a mapping dataset, typically generate data by applying the content generating instructions on the rows of the underlying respective logical block. However, they can operate also on logical extensions of the rows of the logical block. Logical extensions can be provided by the dr:logicalExtension or dr:logicalExtensions properties.

Triples Datasets

A triples dataset is a set of triples represented by a logical graph. A triples dataset MUST contain exactly one logical graph, provided by the dr:logicalGraph property. The triples in the logical graph will be included as they are in the RDF dataset produced by the D2RML processor (after possible adding them to the specified named graphs).

<#TRIGFile>
   a dris:FileSource ;
   dris:path "c:/data/dataset.ttl" .

<#LogicalDataset>
   a dr:TriplesDataset
   dr:logicalGraph [
      dr:source <#TRIGFile>
   ] .


Defined Columns

A defined column represents a logical block that is added to the current logical row by applying a function on value maps defined over the current logical block row, or already computed logical extension thereof. A defined column is an instance of dr:DefinedColumn. The logical cell content of the columns of the added logical block are obtained by applying a function, specified by the dr:function property. The value of dr:function must be a IRI that identifies a certain function. A function may return a single logical column, or multiple logical columns, each possibly consisting of one or more value elements, hence the result is interpreted as a logical block. Reference to the logical columns of the added logical block in value maps is achieved using the column name or, in case of the new logical block consists of multiple logical columns, using the expression defined-column-name.subcolumn name where subcolumn-name is a name provided by the function to the column it returns. If a defined column returns a single column, it is accessible by default also by the expression defined-column-name.result.

In case, the evaluation of a function return more than one logical rows (e.g. in a regular expression extract match operation), the dr:selector property permits to determine if some particular values only well be kept, in particular the first or the last element, by assigning it the value dr:firstElement and dr:lastElement respectively.

In the following example, the drop:extractMatch function is used. Because the regex parameter has two capturing groups, the logical block that will be added for each original logical row will consist of two logical columns, accessible by the ADDRESS.match#1 and ADDRESS.match#2 column names.

<#DataMapping>
   dr:logicalBlock [
      a dr:JSONItemArray;
      dr:source <#DataSource> ;
      dr:iterator "$.results" ;
   ] ;

   dr:logicalExtension [
      a dr:DefinedColumn ;
      dr:name "ADDRESS" ;
      dr:function drop:extractMatch ;
      dr:parameterBinding [
         dr:parameterName "input" ;
         dr:column "$.address" ;
      ] ;
      dr:parameterBinding [
         dr:parameterName "regex" ;
         dr:constant "^(.*?)(?:\\s+([0-9]+\\s?[A-Z]?))?$"  ;
      ] ;
   ]
   dr:predicateObjectMap [
      dr:predicate ex:streetName ;
      dr:objectMap [
         dr:column "ADDRESS.match#1" ;
         dr:termType rr:Literal ;
      ] ;
   ] ;
   ...


Transformations

A transformation adds to the current logical a logical block that is obtained from an information source, which may or may not be different from the information source underlying the current logical-row.

The logical block of a transformation is provided by the dr:logicalBlock property. The logical block will typically involve parameters for which bindings should be provided by transformation. As in the case of defined columns, the values to theses parameters are supplied by parameter bindings that bind a parameter name to value constructed from the logical columns a logical row.

Since a transformation fetches data from an information source, the interpretation of the data is provided by the logical block specification included in the relevant dr:LogicalBlock instance. The data provided by a transformation for each logical row are accessible through the expression transformation-name~~column-name where transformation-name is the name provide in the definition of the transformation, and column-name a name of a logical column of the logical block provided by the transformation.

In the following example, <#MappingDataset> applies on its underlying logical rows uses a transformation, with a single parameter, wikilink, which is used to formulate a query a the corresponding Wikidata SPARQL Endpoint in order to obtain the respective Wikidata URI. It is assumed that the logical list of <#MappingDataset> includes a column named WIKIPEDIA-LINK that contains wikipedia URIs.

<#WikidataData>
   a dr:LogicalBlock
   dr:logicalBlock [
      dr:source <#WikidataEndpoint> ;
      dr:sparqlSelectQuery "PREFIX schema:  PREFIX wdt:  SELECT ?wikidataId WHERE { <{@@wikilink@@}> schema:about ?wikidataId }" ;
   ] ;
   dr:parameter [
      a dr:DataParameter  ;
      dr:name "wikilink" ;
   ] .

<#MappingDataset>
...
   dr:logicalExtension [
      a dr:Transformation ;
      dr:logicalBlock <#WikidataData> ;
      dr:name "WIKI-TRANSFORMATION" ;
      dr:parameterBinding [
         dr:parameterName "wikilink" ;
         dr:column "WIKIPEDIA-LINK" ;
      ] ;
   ] ;
   dr:predicateObjectMap [
      dr:predicate ex:wikidataLink ;
      dr:objectMap [
         dr:column "WIKI-TRANSFORMATION~~wikidataId" ;
         dr:termType rr:IRI ;
      ] ;
   ] ;
...


Constant and Constant List Value Maps

A constant value map generates a value set without considering logical cells of the current logical row and adding to it a single fixed value element. The only value element in the value set of a constant value map is provided by the dr:constant property.

A constant list value map generates a value set without considering the logical cells of the current logical row and adding to it several fixed value elements in a predefined order. The value elements of the value set of a constant list value map are the values provided by the dr:constantList property, which should be an RDF list of literals or IRIs. The order of the elements is preserved in the value set.

The value type of the value set elements of a constant value map or a constant list value map is either IRI or literal. If it is a literal, its datatype is determined by the literal.

Column Value Maps

A column value map generates a value set by copying to it all elements of a logical cell content. The logical column of that logical cell is the logical column addressable by the column name expression that is the value of the dr:column property.

The value type of the value set elements of a column value map is IRI or literal if the underlying logical input is a SPARQL query result, and a literal with datatype xsd:string otherwise.

Template Value Maps

A template value map generates a value set by concatenating elements of one or more logical cell contents and possibly also fixed strings. The way the elements will be concatenated is determined by a string template that is the value of the dr:template property. A string template contains fixed string parts and it can reference column names by enclosing them in curly braces { ... }. If the logical cell content of a column name involved in a string template is empty, the resulting value set is empty. If some logical cell contents contain more than one value elements, the resulting value set contains all values obtained by substituting the column names in the string template in all possible ways. A namespace defined in the D2RML document can be reference from within a string template by as {@namespace-prefix} where namespace-prefix is the prefix of a defined namespace.

For example, if the source data for logical row is the following JSON object

{ "companies": [ "COMP1", "COMP2" ] }, {"employees": [ "EMP1", "EMP2" ] }


and assuming the definition @prefix ex: <http://data.example.com/>, the value set generated for the string template

"{@ex}{$.companies}/{$.employees}"


will contain the following value elements.

"http://data.example.com/COMP1/EMP1"
"http://data.example.com/COMP1/EMP2"
"http://data.example.com/COMP2/EMP1"
"http://data.example.com/COMP1/EMP2"


The value type of the value set elements of a template value map is literal with datatype xsd:string.

As mentioned before, if the logical cell content of a column name involved in a string template is empty, the resulting value set is empty. If this is the case the values set that will be generated will be empty. However, a string template may contain also optional template parts, that act as usual fixed parts, but if the resulting expression is empty, it is just ignore and does not cause the entire value set of the template to be empty. Optional template parts are enclosed within <<...>>.

Extending the above example, if the source data for logical row is the following JSON object

{ "companies": [ "COMP1", "COMP2" ] }, {"employees": [ "EMP1", "EMP2" ] }, {"departments": [  ] }


the value set generated for the string template

"{@ex}{$.companies}<<-{$.departments}>>/{$.employees}"


will be the same value elements as before because {$.departments} despite having an empty value set is inside an optional template part.

A string template can also contain references to external parameters. Using the convention for parameters they may referenced as {@@parameter-name@@} for an external parameter with name parameter-name and the expression will be substituted by the value provided to the parameter.

Conditional Value Maps

A value map may be a conditional value map, in which case the value set generated by it is dependent on the satisfaction of a condition. The condition is specified by a dr:condition property whose value is an instance of dr:Condition. If the condition evaluates to false the resulting value set is empty, otherwise it is the values set that would be produced if the condition was absent.

Case Maps

A value map may specify a list case maps, using the dr:exclusiveCases or dr:nonExclusiveCases. Each case map in the list is a value map having necessarily a dr:condition property, apart possibly from the last one that may not have a condition. The several case maps in the list are evaluated one by one, and if the corresponding condition evaluates to true, the resulting value set are added to the value set of the including value map. In case of dr:exclusiveCases, once a case map evaluates to true no further case maps in the list of case maps are considered. In case of dr:nonExclusiveCases, all case map evaluates are considered.

Term Maps

A term map is a value map that is a rule for generating one or more RDF terms from a logical row. The value elements that will give rise to the RDF terms are the elements of the underlying value set which is created as described above. A term map supplies all necessary information to generate the final RDF terms from the value set.

Each term map has a term type, which determines the kind of the generated RDF terms, i.e. whether they will be IRIs, blank nodes or literals. The term type is specified by the dr:termType property, whose value MUST be one of rr:IRI, rr:BlankNode or rr:Literal.

<#Mapping>
   dr:logicalBlock [
      a dr:CSVTable;
      dr:source <#DataSource> ;
	  dr:headerRecord true;
	  dr:delimiter ",";
   ] ;

   dr:subjectMap [
      dr:template  "http://ex.org/{ID}" ;
      dr:class ex:Company ;
   ] ;


dr:predicateMap [
   dr:constant ex:main ;
   dr:condition [
       dr:column  "TYPE_ID" ;
       drop:eq "1" ;
   ] ;
]


dr:predicateMap [
   dr:exclusiveCases ( [
      dr:constant ex:main ;
      dr:condition [
        dr:column  "TYPE_ID" ;
           drop:eq "1" ;
        ] ;
   ] [
      dr:constant ex:secondary ;
      dr:condition [
         dr:column  "TYPE_ID" ;
         drop:eq "2" ;
      ] ;
   ] [
      dr:constant ex:other ;
   ] )
]


dr:objectMap  [
   dr:column "name" ;
   dr:termType  rr:Literal ;
   dr:language "en"
] ;


<#Output1>
  a dr:RDFOutput ;
  dr:name "NEW" .

<#Output2>
  a dr:RDFOutput ;
  dr:name "CHANGES" .

<#UpdateMapping>
   dr:logicalArray [
      a dr:JSONItemArray;
      dr:source <#UpdateSource> ;
      dr:iterator "$.results" ;
   ] ;

   dr:logicalOutputMap [
      dr:exclusiveCases ( [
         dr:constant  <#Output1> ;
         dr:condition [
            dr:column "$.updateType" ;
            drop:eq "New" ;
         ] ;
      ] [
         dr:constant  <#Output2>  ;
         dr:condition [
            dr:column "$.updateType" ;
            drop:eq "Changed" ;
         ] ;
      ]
   ] ;

   ...


Language Maps

A language map is a value map that is a rule for generating language tags to be used in RDF literals. These language tags are the value elements of the underlying value set.

dr:objectMap  [
   dr:column "name" ;
   dr:termType  rr:Literal ;
   dr:languagMap [
      dr:exclusiveCases ( [
         dr:constant "fr" ;
         dr:condition [
            dr:column  "Language" ;
            drop:eq "1" ;
         ] ;
      ] [
         dr:constant "nl" ;
         dr:condition [
            dr:column  "Language" ;
            drop:eq "2" ;
         ] ;
      ]  ;
   ] );
]


Parameter Bindings

A parameter binding is a value map that is a rule for binding parameter names to the value. The values are the value elements of the underlying value set. A parameter map must include a dr:parameterName property, which determined the name of the parameter for which the binding will be generated.

Predicate Object Maps

A predicate object map is a rule for generating the predicate and object of triples from a logical row of a logical array or logical table. It must appear within a triples map, and it must specify one or more predicate maps using the dr:predicateMap property for generating the predicates, and one or more object maps using the dr:objectMap property for generating the objects. A predicate map generates all possible triples having as subject an element of the enclosing subject map, as predicate an element of the predicate maps it contains, and as object an element of the objects maps it contains.

The shortcut properties dr:predicate and dr:object are also provided; ?x dr:predicate ?y is a shortcut for ?x dr:predicateMap [ dr:constant ?y ], and ?x dr:object ?y is a shortcut for ?x dr:objectMap [ dr:constant ?y ].

Triples Maps

A triples map represents a rule for obtaining from each logical row of a logical array or logical table zero or more RDF triples. A triples map uses the logical array or logical table, provided by the dr:logicalArray and dr:logicalTable, respectively, of the enclosing mapping dataset.

Apart from the other properties discussed below, a logical dataset may include one or more graph maps, through the dr:graphMap property, to specify the named graphs to which all triples of the logical dataset will be added.

RDF triples are generated from the underlying logical array or logical table, possibly extended by logical extensions using a combination of a subject map and zero or more predicate object map. A triples map MUST contain at least one subject map.

The subject map is provided by the dr:subjectMap property, which provides the subjects of the triples to be generated. The predicate object maps are provided using the dr:predicateObjectMap property, which provide the predicate and objects of the triples. For each predicate object map, an RDF triple is generated for each possible combination subject predicate object, where subject belongs to the value set of the subject map, predicate belongs to the value set of some predicate map of the predicate object map and object belongs to the value set of some object map of the predicate object map. All value sets may contain zero or more value elements. The shortcut properties dr:predicate and dr:object are also provided; ?x dr:predicate ?y is a shortcut for ?x dr:predicateMap [ dr:constant ?y ] and ?x dr:object ?y is a shortcut for ?x dr:objectMap [ dr:constant ?y ].

If a triples map defined a predicate object map using the dr:inversePredicateObjectMap then, for each possible combination as above, the RDF triple object predicate subject will be generated.

RDF Maps

An RDF map is a value map that is used in the cases where the value elements of the underlying value set are serializations of RDF graphs. The RDF serialization format is determined by the dr:rdfFormat property.

All triples of the underlying RDF graphs will be added as they are in the output map, unless the RDF map contains a dr:sparqlUpdateQuery or dr:sparqlUpdateQueries property, in which case the actions prescribed be the queries will be first applied on the RDF graphs.

RDF maps are within mapping datasets and they are provided by the dr:rdfMap property.

<#DataSource>
   a dris:HTTPSource ;
   dris:uri "http://www.example.org/data/data.rdf" .

<#Mapping>
   dr:logicalArray [
      a dr:XMLItemArray ;
      dr:source <#DataSource> ;
      dr:iterator "/rdf:RDF"
   ] ;
   dr:rdfMap [
      dr:column "/rdf:RDF/ore:Proxy" ;
      dr:rdfFormat formats:RDF_XML
   ] .


In the above example, the data source is an RDF/XML file, which is interpreted as an XML file, and the RDF map specifies that in the logical output will be included only the contents of the /rdf:RDF/ore:Proxy XML elements, interpreted as RDF graphs in the RDF/XML serialization.

Text Lines Maps

An text lines map is a rule for generating text lines from a logical row of a logical array or logical table.

<#SPARQLOutput>
   a dr:PlainTextOutput ;
   dr:outputName "SPARQL" .
<#UpdateMapping>
   dr:logicalArray [
      a dr:JSONItemArray;
      dr:source <#UpdateSource> ;
      dr:iterator "$.results" ;
   ] ;

   dr:textLinesMap [
      dr:logicalOutput <#SPARQLOutput> ;
      dr:template "DELETE {{ <http://ex.org/id/{$.id}> ?p ?q . ?q ?r ?t }} WHERE {{ <http://ex.org/id/{$.id}> ?p ?q . OPTIONAL {{ ?q ?r ?t }} }}" ;
      dr:condition [
         dr:column "$.deleted" ;
         drop:eq true ;
      ] ;
   ] ;


Simple Conditions

A simple condition represents an application of a function that returns a boolean result. It is an instance of dr:SimpleCondition. The function to be used is provided by the dr:function property, and the parameter bindings are provided by the dr:parameterBinding and dr:parameterBindings. The values of these properties are parameters bindings, i.e. value maps that provide their values elements to a parameter. Since they are value maps, the value set they represent consists of more than one value elements. According to the value map processing model of D2RML, if the value maps consist of more than one value elements, the function will be invoked for all combination of such values, and the function will produce multiple results. Because the condition should evaluate to a single true of false value, the dr:conditionEvaluationMode is used to specify the way multiple results will give rise to one. Possible values are drop:logicalSome and drop:logicalAll.

Complex Conditions

A condition condition represents the application of a boolean operator on an appropriate number of condition. It is an instance of dr:ComplexCondition. The relevant boolean operator is specified by the dr:booleanOperator property, and the conditions on which it will be applied by the dr:condition or dr:conditions. The boolean operator may be drop:logicalAnd, drop:logicalOr, or drop:logicalNot. In the first two case two or more conditions should be provided to operate on, while in the last case one condition should be provided. The conditions an be either simple or complex.

RDF Outputs

An RDF output represents an RDF dataset produced by a triples map or an RDF map. It is an instance of dr:RDFOutput. An RDF output MAY have a dris:fileFormat property, to specify the form of serialization. If absent, the default value is formats:TriG.

<#MainOutput>
   a dr:RDFOutput ;
   dr:outputName "MAIN" ;
   dris:fileFormat formats:N-Quads .

<#MainMapping>
   ...

   dr:triplesMap [
      dr:logicalOutput <#MainOutput> ;
      ...
   ] .


<#Specification>
   a dr:D2RMLSpecification ;
   dr:logicalDatasets ( <#ProviderMapping> <#DatasetMapping> ) ;

<#ProviderSource>
    a dris:HTTPSource ;
    dris:uri "http://example.org/api/dataset/list" .

<#ProviderMapping>
   dr:logicalArray [
      a dr:JSONItemArray ;
      dr:source <#ProviderSource> ;
      dr:iterator "$" ;
   ] ;

   # Define dynamically the source
   dr:triplesMap [
      dr:logicalOutput dris:CurrentD2RMLDocument;

      rr:subjectMap [
         rr:template "#DatasetSource{$.datasetId}" ;
         rr:class dris:HTTPSource ;
      ] ;

      rr:predicateObjectMap [
         rr:predicate dris:uri ;
         rr:objectMap [
            rr:column "$.url" ;
            rr:termType rr:Literal ;
         ] ;
      ] ;
   ] ;

   # Attach the source to the map
   dr:triplesMap [
      dr:logicalOutput dris:CurrentD2RMLDocument;

      rr:subjectMap [
         rr:constant <#DatasetMappingLogicalArray> ;
      ] ;

      rr:predicateObjectMap [
         rr:predicate dr:source ;
         rr:objectMap [
            rr:template "#DatasetSource{$.datasetId}" ;
            rr:termType rr:IRI;
         ] ;
      ] ;
   ] .

<#DatasetMappingLogicalArray>
   a dr:XMLItemArray ;
   dr:iterator "." .

<#DatasetMapping>
   dr:logicalArray <#DatasetMappingLogicalArray> ;

   ...


Plain Text Outputs

A plain text output represents generic textual content produced by a text lines map. It is an instance of dr:PlainTextOutput.

<#SPARQLOutput>
   a dr:PlainTextOutput ;
   dr:outputName "SPARQL" .

<#MainMapping>
   ...

   dr:textLinesMap [
      dr:logicalOutput <#SPARQLOutput> ;
      ...
   ] .
